A high quality, self-aligning springloaded/- piston sensor is the heart of each
BETA switch.
The limited piston travel transmits pressure at the process diaphragm directly to the microswitch, with no intervening linkages or mechanisms while providing full protection against high overrange pressure.
The piston sensor is isolated from the process fluid by a diaphragm and
static O-ring seal and retained by a process connection port.
These (3) are the only process wetted parts and are available in an extensive range of materials.*
(*) A BETA vacuum switch contains also a vacuum piston and spring (SS 316) on the wetted parts side.
Please refer to the “downloads” section for a PDF version of our latest catalogue with more detailed information.
The weatherproof C-Series, with cast aluminum or 316SS enclosures. (Optional also Eex ia/b IIC T6). Pressure ranges starting from 2 mbar to 350 bar. Vacuum ranges / Differential ranges and Temperature ranges available. Several options and specials possible.
View C-seriesThe explosion proof (EX II 2 G/D Ex d/tb T6 G/Db) W-series, in cast aluminum, SS316 or V5 series in cast iron enclosures. Pressure ranges starting from 2 mbar to 350 bar. Vacuum ranges / Differential ranges and Temperature ranges available. Several options and specials possible.
view W-seriesThe OEM range BETA MINI switch is anodised aluminum enclosure fixed Hirschmann connector. Pressure ranges starting from 0.3 bar to 300 bar. Fluid power (hydraulic) range up to 540 bar Vacuum ranges and Temperature ranges available. Limited options and specials possible.
View b-seriesM0, V - and Z-series have been obsoleted in the BETA product range, please refer to the W8 (SS316 EEx –D IIC T6 ) series.
view legacy products
